The Blue Sea WeatherDeck Waterproof Fuse Panel Gray 2 Position from Nomadic Supply Company® is an IP67 waterproof 2-circuit ATO/ATC fuse panel rated 15A per circuit and 30A total at 12V DC, with bicolored circuit LEDs (red=off, green=on), backlighting, and reinforced polycarbonate construction for flybridge and open cockpit installations.
The Blue Sea WeatherDeck Waterproof Fuse Panel Gray 2 Position (4302-BSS) from Nomadic Supply Company® is an IP67 waterproof 2-circuit ATO/ATC fuse panel rated 15A per circuit and 30A total at 12V DC, with bicolored circuit LEDs (red=off, green=on), backlighting, and reinforced polycarbonate construction for flybridge and open cockpit installations.
Blue Sea Systems PN: 4302
Blue Sea Systems Color: Gray
Blue Sea WeatherDeck Waterproof Fuse Panel Gray 2 Position (4302-BSS) Features:
- Panel front rated IP67 when properly mounted with watertight mounting gasket
- IP67 – protected against immersion up to 1 meter for 30 minutes
- Designed for flybridge and open cockpit applications
- Independent label back lighting circuit for remote switching and dimming
- Each panel can be mounted in four different orientations
- Integrated ATO/ATC fuse based circuit protection
- Bicolored LEDs illuminate circuit labels to quickly identify OFF (Red), ON (Green), or Blown (No Color) circuits. No lights in any position likely indicate there is no power to the panel.
Blue Sea WeatherDeck Waterproof Fuse Panel Gray 2 Position (4302-BSS) Specifications:
- Weatherproof: Waterproof
- Positions: 2
- Nominal Voltage: 12v DC
- Circuit Protection: Fuse
- Maximum Amperage: 15A @ 12v DC (per circuit)
- Panel Cumulative Rating: 30A
- Backlit Label: Bicolored LED
- Backlighting Amperage: 10mA/illuminated Circuit
- Backlighting Voltage: 12v DC
- Height: 2.6″
- Width: 3.88″
- Depth: 2.5″
Blue Sea Systems Included:
- (2) 4150 WeatherDeck Toggle Switch SPST – ON-OFF
- (1) 4215 Waterproof DC Label Kit – 30 Black Square Labels V1
- (2) 5242 ATO/ATC Fuse – 15 Amp
| Weight | 0.5 lbs |
|---|---|
| Dimensions | 6 × 6 × 5 in |
